[ BSM-BIGGESTONE ] FR Series 2016, BOTTOM SEALING BAG ON ROLLMAKING MACHINE WITH CORE & CORELESS, BOTTOM LINE BAG ON ROLLMAKING MACHINE with or without Core Bag

BS-32FR1, BS-32FR2, BS-32FR2-E2

BOTTOM SEALING BAG ON ROLL MAKING MACHINE WITH CORE & CORELESS

BOTTOM LINE BAG ON ROLL MAKING MACHINE with or without Core Bag

BOTTOM SEALING BAG ON ROLLMAKING MACHINE WITH CORE & CORELESS,   BOTTOM LINE BAG ON ROLLMAKING MACHINE with or without Core Bag

BOTTOM SEALING BAG ON ROLLMAKING MACHINE WITH CORE & CORELESS,   BOTTOM LINE BAG ON ROLLMAKING MACHINE with or without Core Bag BOTTOM SEALING BAG ON ROLLMAKING MACHINE WITH CORE & CORELESS,   BOTTOM LINE BAG ON ROLLMAKING MACHINE with or without Core Bag

With Core & Without Core


AUTOMATIC HIGH SPEED PERFORATED BOTTOM SEALING BAGS ON ROLL MAKING MACHINE



FR1 Series
1. The FR1 Series machine model have BS-20FR1/28FR1/32FR1/40FR1/50FR1 , It's can make perforated Bottom sealing bag in one machine.
2.This machine have one production line and equipped one photo cell for print bag , can make one print perforated bottom sealing bag.
3.This machine equipped uses Semi-Automatic Winder Equipment With Core & without Core
4.Electromagnetic clutch & brake ensure accuracy of bag sealing & cutting.
5.This model is also available with servo motor control.
6.This machine will stop automatically and sound alarms when the film roll is finished, the printing photo cell fails , the bags stacked up on the cutting blade and the sealing, temperature is not enough.

SPECIFICATION:
BOTTOM SEALING BAG ON ROLLMAKING MACHINE WITH CORE & CORELESS,   BOTTOM LINE BAG ON ROLLMAKING MACHINE with or without Core Bag


FR2 Series
1. The FR2 Series machine model have BS-28FR2/32FR2/40FR2/50FR2 , It's can make perforated Bottom sealing bag in one machine.
2.This machine have two production line and equipped one photo cell for print bag , can make one print & two no print perforated bottom sealing bag.
3.This machine equipped uses Semi-Automatic Winder Equipment With Core & without Core
4.Electromagnetic clutch & brake ensure accuracy of bag sealing & cutting.
5.This model is also available with servo motor control.
6.This machine will stop automatically and sound alarms when the film roll is finished, the printing photo cell fails , the bags stacked up on the cutting blade and the sealing, temperature is not enough.

SPECIFICATION:
BOTTOM SEALING BAG ON ROLLMAKING MACHINE WITH CORE & CORELESS,   BOTTOM LINE BAG ON ROLLMAKING MACHINE with or without Core Bag


FR2-E2 Series
1. The FR2-E2 Series machine model have BS-28FR2-E2/32FR2-E2/40FR2-E2/50FR2-E2 , It's can make perforated Bottom Sealing bag in one machine.
2.This machine have two production line and equipped two photo cell for print bag , can make two print perforated bottom sealing bag.
3.This machine equipped uses Semi-Automatic Winder Equipment With Core & without Core
4.Electromagnetic clutch & brake ensure accuracy of bag sealing & cutting.
5.This model is also available with servo motor control.
6.This machine will stop automatically and sound alarms when the film roll is finished, the printing photo cell fails , the bags stacked up on the cutting blade and the sealing, temperature is not enough.

SPECIFICATION:
BOTTOM SEALING BAG ON ROLLMAKING MACHINE WITH CORE & CORELESS,   BOTTOM LINE BAG ON ROLLMAKING MACHINE with or without Core Bag
